STAX STAX SRM 007-T MK2

The new SRM-007tII is flagship model of a driver unit intended exclusively for earspeakers characterized by their wide range, high dynamic range and outstanding operating features with full allowance made for SACD and other new-generation high-density formats. The ultra-light polymer film, only a few microns thick, realizes unprecedented response and a high degree of resolution

Tech Specs
IMPROVED FREQUENCY RESPONSE
Newly improved circuit raises the frequency response to 100kHz (from 70kHz) to accommodate newer generation audio formats such as SACD and DVD-A.



PURE BALANCE AMPLIFIER
The electrostatic transducer is driven by electrodes set on both sides of the diaphragm which carry the push-pull signals. This is thus virtually the only replay system that enables the listener to enjoy replay unique to balance transmission without the need to pass through a transformer or inversion amplifier.



HEATER POWER SUPPLY
Adopting a rectifier circuits combining low-noise, low-loss Schottky barrier diodes and large electrolytic capacitors. Low-ripple DC power source improves the SN ratio.



OUTPUT STAGE
A simple two-stage amplifier configuration using high-voltage dual triode tube 6FQ7(6CG7) delivers straightforward properties that are transparent and clear sound quality.



INPUT STAGE
Employs Hand pick low noise FET and 6 acoustic high sound quality relays. Simultaneous switching system adopted from SRM-T2 , input source is isolated of direct current and no interference between different devices.



HIGH QUALITY VOLUME CONTROL
High sound quality quadruple volume unit which makes XLR inputs as well as any analog line level inputs possible







SRM-007tII SPECIFICATIONS:

Type: Vacuum tube output stage Low noise dual FET input Class A operation, Pure balance DC amplifier configuration Earspeaker driver unit

Vacuum Tube: 4 (6FQ7 / 6CG7)

Frequency Response: DC to 100,000Hz +0,-1.5dB w/ SR-007 or SR-404

High Harmonic Distortion: Max. 0.02% (with 1kHz, 100V r.m.s. )

Gain: 54dB (x500)

Input Terminal: 3 ( XLR x 1, RCA x 2) with 1 RCA parallel out

Rated Input Level: 200mV / 100V Outputs

Max. Input Level: 30V r.m.s. at min. volume

Input Impedance: 50Kohm, 50kohm x 2 during balance

Max. Output Voltage: 340V r.m.s. (1kHz)

Standard Bias Voltage: PRO 580V x 2

Power Voltage Frequency: 117V (50Hz / 60Hz)

Power Consumption: 55W

Temperature & Humidity: 0 to 35ºC / 90% max. without condensation

Dimensions: 7.7 (W) x 4.1 (H) x 16.5 (D) in

Weight: 10.4lbs
