Bricasti Design Bricasti M1 MDx
Preis: 4.950,00 €
| Gebrauchtgerät
Produktdetails
- Produktgruppe
- D/A Wandler
- Hersteller
- Bricasti Design
- Funktion
- einwandfrei
- Alter
- 8 Jahre Nach Schätzung
- Gebrauchszustand
- gebraucht
- Optik
- neuwertig
- Zubehör
- komplett mit OVP
- Neupreis
- 12.000,00 €
- Preis
- 4.950,00 €
- Weitere Informationen
- http://www.bricasti.com/
Beschreibung
Bricasti M1 D/A Converter with MDx board – Mint condition, original packaging, manual, and remote control included.
This unit represents the ultimate evolution of the Bricasti M1 D/A converter, featuring the integrated MDx (Multiple Digital eXcellence) digital engine.
Key Features:
Total Separation: Two completely isolated channels, each featuring its own analog board, its own DAC (ADI 1955 in mono configuration), and its own dedicated linear power supply.
Triple Power Supply: In addition to the two transformers for the analog channels, a third independent transformer is dedicated to the digital section. This prevents electrical noise from the processors from polluting the audio signal.
Aluminum Chassis: The enclosure is CNC-milled from solid aluminum to ensure superior shielding and resonance control.
The MDx designation identifies the new digital processing platform that replaces all previous versions. Key improvements include:
Dual-Core SHARC Processor: Utilizes the powerful Analog Devices ADSP-SC584 chip to manage digital filtering and clock synchronization with significantly higher computing power.
Clocking and Jitter: The new engine optimizes the master clock throughout the entire circuit, reducing jitter to infinitesimal levels (approx. 6 picoseconds) and improving signal timing stability.
Format Support: With the MDx board, the USB input now supports DSD256 (Native and DoP) and PCM up to 384kHz/24-bit, ensuring compatibility with the latest high-resolution files.
Specs:
Digital Inputs USB, AES/EBU, S/PDIF (RCA and BNC), Toslink
Analog Outputs Balanced XLR and Unbalanced RCA
PCM Conversion Up to 384 kHz / 24-bit
DSD Conversion DSD64, DSD128, DSD256 (via USB)
Frequency Response 10 Hz – 20 kHz (+0, -0.2 dB)
Dynamic Range > 120 dB
Weight Approx. 6.8 kg
We are dealer and distributor in Italy and ship worldwide.
We accept wire transfer on our company bank account or PayPal (adding 6% commissions).
You can find the advice on our website at: www.mondoaudio.it/prodotti/usato/
This unit represents the ultimate evolution of the Bricasti M1 D/A converter, featuring the integrated MDx (Multiple Digital eXcellence) digital engine.
Key Features:
Total Separation: Two completely isolated channels, each featuring its own analog board, its own DAC (ADI 1955 in mono configuration), and its own dedicated linear power supply.
Triple Power Supply: In addition to the two transformers for the analog channels, a third independent transformer is dedicated to the digital section. This prevents electrical noise from the processors from polluting the audio signal.
Aluminum Chassis: The enclosure is CNC-milled from solid aluminum to ensure superior shielding and resonance control.
The MDx designation identifies the new digital processing platform that replaces all previous versions. Key improvements include:
Dual-Core SHARC Processor: Utilizes the powerful Analog Devices ADSP-SC584 chip to manage digital filtering and clock synchronization with significantly higher computing power.
Clocking and Jitter: The new engine optimizes the master clock throughout the entire circuit, reducing jitter to infinitesimal levels (approx. 6 picoseconds) and improving signal timing stability.
Format Support: With the MDx board, the USB input now supports DSD256 (Native and DoP) and PCM up to 384kHz/24-bit, ensuring compatibility with the latest high-resolution files.
Specs:
Digital Inputs USB, AES/EBU, S/PDIF (RCA and BNC), Toslink
Analog Outputs Balanced XLR and Unbalanced RCA
PCM Conversion Up to 384 kHz / 24-bit
DSD Conversion DSD64, DSD128, DSD256 (via USB)
Frequency Response 10 Hz – 20 kHz (+0, -0.2 dB)
Dynamic Range > 120 dB
Weight Approx. 6.8 kg
We are dealer and distributor in Italy and ship worldwide.
We accept wire transfer on our company bank account or PayPal (adding 6% commissions).
You can find the advice on our website at: www.mondoaudio.it/prodotti/usato/
